PV5000 PRO Rack Series (3-5.2KW)

High Frequency Solar Inverter PV 450V | MPPT 100A | WIFI | BAT-CAN

PV5000 PRO is a multi-function inverter/charger, combining functions of inverter, MPPT solar charger and battery charger to offer uninterruptible power support in portable size. PV5000 PRO Series can run without battery. The Maximum PV array open circuit voltage can reach 450V and MPPT voltage is 150~430Vdc, which Can help customers make full use of solar energy.

  • Description

■ Pure sine wave inverter

■ Configurable input voltage range for home appliances and personal computers via LCD setting

■ Configurable battery charging current based on applications via LCD setting

■ Configurable AC/Solar Charger priority via LCD setting

■ Compatible to mains voltage or generator power

■ Auto restart while AC is recovering

■ Overload/ Over temperature/ short circuit protection

■ Smart battery charger design for optimized battery performance

■ Cold start function

■ Parallel operation with up to 3 units

■ WIFI remote monitoring (optional)

MODEL PV50-3048 PRO PV50-4048 PRO PV50-5248 PRO
Nominal Battery System Voltage 48VDC
Rated Power 3000VA / 3000W 5200VA / 5200W 5200VA / 5200W
Surge Power 6000W 8000W 10400W
Waveform Pure sine wave
AC Voltage Regulation (Batt.Mode) 230VAC±5%(Setting)
Inverter Efficiency(Peak) 90%
Transfer Time 10ms (UPS / VDE4105) / 20ms (APL)
Voltage 230VAC±5%
Selectable Voltage Range 170~280VAC(UPS) / 90~280VAC(APL) / 184~253VAC(VED4105)
Frequency Range 50Hz / 60Hz(Auto sensing)
Normal voltage 48VDC
Floating Charge Voltage 54.8VDC
Overcharge Protection 60VDC
Maximum PV Array Open Circuit Voltage 450VDC
Maximum PV input voltage 18A 18A 27A
Charging Algorithm 3-Step (Flooded Battery, AGM / GEL / LEAD Battery), 4-Step (Li)
Maximum PV Array Power 4000W 5000W 6000W
PV Array MPPT Voltage Range 150~430 VDC
Maximum Solar Charge Current 80A 80A 100A
Maximum AC Charge Current 60A 60A 80A
Maximum Charge Current 80A 80A 100A
Machine Dimension (W*H*D)(mm) 468*86.3*400
Package Dimension (W*H*D)(mm) 546*185*540
N.W(kg) 12.5
G.W(kg) 14
Warranty 2years
Parallel operation 3 units
Humidity 5% to 95% Relative humidity (Non-condensing)
Operating Temperature 0°C~50°C
Storage Temperature -25°C~60°C
