■ Pure sine wave inverter
■ Configurable input voltage range for home appliances and personal computers via LCD setting
■ Configurable battery charging current based on applications via LCD setting
■ Configurable AC/Solar Charger priority via LCD setting
■ Compatible to mains voltage or generator power
■ Auto restart while AC is recovering
■ Overload/ Over temperature/ short circuit protection
■ CAN/RS485 communication for BMS
■ Cold start function
■ WiFi remote monitoring (optional)
| MODEL | PH18-8048 PRO | PH18-10048 PRO |
| Nominal Battery System Voltage | 48VDC | |
| INVERTER OUTPUT | ||
| Rated Power | 8000W | 10000W |
| Surge Power | 16000W | 20000W |
| Waveform | Pure Sine Wave | |
| AC Voltage Regulation (Batt.Mode) | 230VAC±5% | |
| Output Frequency | 60Hz or 50Hz | |
| Inverter Efficiency(Peak) | 90% | |
| Transfer Time | 10ms (UPS) 20ms (APL) | |
| AC INPUT | ||
| Nominal Input Voltage | 230VAC | |
| Max AC Input Voltage | 300VAC | |
| Selectable Voltage Range | 170~280VAC (UPS) / 90~280VAC (APL) / 184~253VAC(VDE4105) | |
| Frequency Range | 50Hz / 60Hz(Auto detection) | |
| BATTERY | ||
| Normal Voltage | 48VDC | |
| SOLAR CHARGER & AC CHARGER | ||
| AC Charging Current | 2-120A | 2-160A |
| Maximum PV Array Open Circuit Voltage | 450VDC | |
| PV Array Open Circuit Voltage | 150-430VDC | |
| Cold Start Voltage | 46VDC | |
| Solar Charging Current | 80A/80A | 100A/100A |
| Default Charging Current | 80A/80A | |
| Maximum Charge Current | 160A | 200A |
| Charging Algorithm | 3-step (Flooded Battery / AGM / GEL/ LEAD Battery), 4-step(LI) | |
| GENERAL DATA FEATURES | ||
| Operating Temperature | -10°C~50°C | |
| Storage Temperature | -15°C ~60°C | |
| Machine Dimension (W*H*D)(mm) | 600*503*141.2 | |
| Package Dimension (W*H*D)(mm) | / | |
| N.W(kg) | 21 | |
| G.W(kg) | / | |
| Warranty | 2 year | |
| CERTIFICATION & STANDARDS | ||
| EN IEC62368-1
CE-LVD (EN IEC62109-1, EN IEC62109-2) Rohs-(2011/65/EUand2015/863/EU) CE-LVD (BS IEC62109-1:2010, BS EN IEC62109-2:2011) UKCA |
||
