🔋 Versatile Capacity Options
Available in 51.2V configurations: 50Ah / 100Ah / 105Ah / 150Ah / 200Ah
Energy: 2.56kWh to 10.24kWh
Max Output Power: 10kW
✅ Key Features
■ High energy density for compact power
■ Fast charging capabilities
■ 6000+ life cycles with LiFePO₄ chemistry
■ Intelligent BMS with communication for smart control
■ IP67-rated enclosure for full dust and water protection
■ Low maintenance and long design life—up to 12 years
■ Storage duration of up to 24 months (fully charged)
■ Wide operating temperature: -10°C to 55°C
■ Eco-friendly and cobalt-free design
📦 Applications
Ideal for AGVs, forklifts, sightseeing carts, golf carts, and marine power systems.
| Technical Data | LP22-4850 | LP22-48100 | LP22-48105 | LP22-48150 | LP22-48200 |
| ELECTRICAL | |||||
| Nominal Voltage | 51.2V | ||||
| Nominal Capacity | 50Ah | 100Ah | 105Ah | 150Ah | 200Ah |
| Battery Energy | 2560Wh | 5120Wh | 5376Wh | 7680Wh | 10240Wh |
| Max. output power | 2.5KW | 5KW | 5KW/ 10KW | 5KW/ 10KW | 10KW |
| Max Charge Current | 20A | 100A | 100A | 100A | 100A |
| Charging Cut-off Voltage | 57.6V± 0.2V | ||||
| Max Discharge Current | 50A | 100A/100A | 100A/200A | 100A/200A | 200A |
| Discharging Cut-off Voltage | 44.8V± 0.2V | ||||
| Cell Type | LiFePO4 Battery | ||||
| Terminal | M8 screw / Anderson | ||||
| Case Material | Metal Box | ||||
| Communication Mode | RS485 or BT (optional) | ||||
| Charge Temperature Range | 0 ~ 45°C | ||||
| Discharge Temperature Range | -10 ~ 55°C | ||||
| Cycle Life | 6000 cycles | ||||
| Designed Life | 12 Years | ||||
| Colour | Black / white | ||||
| Ingress Protection | IP67 | ||||
| Warranty | 5 years | ||||
| MECHANICAL | |||||
| Machine Dimension (W*H*D) (mm) | / | 646*195*438 | / | / | / |
| Package Dimension (W*H*D) (mm) | / | / | / | / | / |
| N.W (kg) | / | / | / | / | / |
| G.W (kg) | / | / | / | / | / |
| * Variations in dimensions and weights may occur due to production batches. | |||||
| CERTIFICATION & STANDARDS | |||||
| UN38.3, EN 61000-6-1, EN 61000-6-3, IEC62619 | |||||
