+ 3072Wh / 5120Wh LiFePO4, 6000+ Cycles @ 80% DOD,25°C
+ 3KW/5.2KW Pure Sine Wave Output
+ Flexible UPS Mode(24/7)
+ Movable Power Station
+ Off-grid Energy Storage
+ Multiple Devices Can Be Loaded Simultaneously
+ Flexible Recharging Way To Keep Your HBP1800 MT Always On
+ App Remote Control
Specification:
MODEL | HBP18-3024MT | HBP18-5248MT |
---|---|---|
Inverter | ||
Rated power | 3000W | 5200W |
Output voltage waveform | Pure sine wave | |
Output voltage regulation | 230Vac ±5% | |
Output frequency | 50Hz / 60Hz (±0.2Hz) | |
Peak efficiency | 90% | 93% |
Nominal DC input voltage | 24Vdc | 48Vdc |
Standby Consumption | < 25W | |
PV Input | ||
Max solar power input | 1800W | 5000W |
PV max charging current | 60A | 100A |
Combined charging current | 80A | 140A |
Max efficiency | 98.0% max | |
PV array open circuit voltage | 145Vdc | 450Vdc |
PV Array MPPT Voltage Range | 30~120Vdc | 150~430Vdc |
AC Input | ||
AC input voltage | 230Vac ±5% | |
Acceptable input voltage range | 90-280Vac | 170-280Vac |
Nominal input frequency | 50Hz / 60Hz (Auto detection) | |
Transfer time | 10ms typical (UPS, VDE); 20ms typical (APL) | |
AC Charge | ||
Charging current @ Nominal input voltage | 20A/30A | 80A |
Charging Algorithm | 4-step (Li) | |
Output | ||
AC output | 230Vac (Socket *4pcs) | |
Type-C | DC output*1pcs | |
USB (5V 2.4A) | DC output*4pcs | |
USB (12V 1A) | DC output*2pcs | |
Lithium Battery | ||
Energy | 3072Wh | 5120Wh |
Nominal voltage | 25.6V | 51.2V |
Battery capacity | 120Ah | 100Ah |
Protection board | 50A | 30-100A |
Standard charging & discharge current | 50A | 100A |
Operation temperature – Charge | 10~50℃ | |
Operation temperature – Discharge | -20~55℃ | |
Dimension | ||
Product Size (LxWxH) (mm) | 277*452*509mm |
